Dividing Automatics

AED 51,500

Mikhail

6 items live

Item Details

Condition

Perfect inside and out

Usage

Still in original packaging

Posted on: 15th December 2025

Description

PLDS-based divider automation system monitors short-circuit currents flowing through the transmission line network, localizes the damaged section and gives a command for switching on automatic reserve entry.

Overhead Power Line Diagnostics System (PLDS) is designed to remotely monitor the state of the wire without need for on-site visits by service personnel, and it signals the possibility of emergency situations in the early stages.

The system tracks the following parameters:

- wire operating parameters: temperature, current, sag angle, vibration amplitude and frequency;

- the occurrance, magnitude, and direction of short circuit current (with event oscillogram capture);

- ice load with weight display in kg;wire sag in meters (over roads, crossing, water bodies, etc.);

- wire break within the anchor section;

- wind loads on the wire, conductor galloping;

- detection of short circuit;

- prevention of wire breakage due to ice deposit formation;

- DLR;

- control of wire temperature, sag angle and distance between wire and obstacle.

BENEFITS:

- Reduction of time for indication of events;

- Reduction of time for finding of place of incident happened;

- Reduction of time for repair;

- Reduction of downtime;

- Reduction of cost of repair and downtime charges.

Customers:

- Electricity transmission and distribution operators (state and private)

- Industrial energy consumers with own OHL;

- Smart city/renewable energy projects.

ServiceEnergy Ltd offers FREE INDUSTRIAL TRIAL FOR POWER GRID COMPANIES!

To demonstrate the systems’ effectiveness, we offer:

- Free trial installation on a selected power line (including full technical support);

- Comprehensive analytics via web interface and Telegram alerts;

- Regulatory support.

System Specification:

Dimensions: 390x130x134 mm

Water resistant IP56

Weight: 3 kg

Communication channels: GSM 900/1800, radio channel (for close-located devices)

Power: from power line

Autonomic activity: minimum 2 hours after de-energized of lines via supercapacitors

Minimal amperage: 10A

Ambient temperature: -40 °C…+50 °C

Wire temperature measurement: -40 °C…+125 °C

Wire current measurement: 0-200 A

Sag angle measurement: 0-90 degrees

Wire vibration frequency: 1-1000 Hz
